USA 2.0 Seplos Smart BMS Lifepo4 Battery Case Stand With 51.2V 280AH 310AH 320AH Lifepo4 Solar Batteries Storage Free Shipping
US 2.0 Seplos BMS Lifepo4 Battery Kits Stand With 51.2V 280AH 310AH 320AH
Lifepo4 For Solar Batteries Storage Free Shipping
Without Battery only battery case with smart BMS
Dear customer :
This is 2.0 original seplos BMS battery case.We will ship it to you from US warehouse,door to door 3-5 days delivery ,Ta x free.Battery case on the way to US warehouse ,expected arrival US warehouse in the early of February.we'd love to reservation for you .
Packing list :
Screws Details:
12 * Phillip Hex M4 * 8mm (PCB board fix)
9 * Phillip Hex M5 * 8mm + Washer + Spring Set(Ground cable and top bracket fix)
7 * Phillip Hex M6 * 25mm + Washer + Spring Set(Front Panel fix)
10 * Phillip Round M3 * 8mm + Washer + Spring Set(BMS and LCD Screen fix)
12 * Phillip Pan M5 * 10mm (Latch fix)
16 * Hexagan Socket Pan M4 * 10mm (P+/P- Terminals fix)
42 * Hexagan Socket Countersunk M4 * 10mm (Handle and battery case)
4 * Phillip Hex M6 * 14mm + Washer + Spring Set(foot fix)
5 * Phillip Hex M8 * 10mm + Washer + Spring Set (P+/P- Bus bar fix)
8 * Phillip Round M5 * 10mm + Washer
Other components includes
6 * Copper bus bars (BMS connection)
15 * Aluminum bus bars (Cell connection)
10 * Epoxy sheet (Between cell and the case)
26 * EVA Tape (Between cells)
1 * PC sheet (Top cover)
Packing List (Without Cells)
1 * Battery Case (Bottom case, Front Panel, Top Bracket, Front Bracket, Top cover)
1 * 48V 200A 16S BMS
1 * 58V 400A Fuse
4 * Handle
2 * PCB Board for BMS and Cell Connection
3 * Upper and Lower Latch lock
1 * LCD Screen
1 * LCD Screen Sticker
4 * Button Cap
3 * Wires (LCD Screen wire, PCB board A and PCB board Connector)
2 * Battery Terminals (P+ Terminal and P- Terminal)
Battery pack wiring (Pack to pack)
Stack the battery packs onto the base. (Maximum 4 packs can be stacked.)
Connect cables between packs.
Connect cable with inverter
