PWM Solar Inverter 24V 2400W 3KVA 110V 50A Pure Sine Wave Inverter Off Grid
PowMr 3KVA Pure Sine Wave Hybrid Solar Inverter 24VDC Input 110VAC Output 50A PWM Solar Charge Controller and AC Charger
Introduction:
This is a multi-function inverter/chargei; combining functions of inverter solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority and acceptable input voltage based on different applications.
Note:
Please Only Use Sealed Lead Acid Battery Or Sealed GEL/AGM Lead-Acid Battery.
The new package is no CD disc, but we have the software, if you need it , feel free to contact us.
Features:
Pure sine wave inverter
Built-in PWM solar charge controller
Configurable input voltage range for home applicances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar charger priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/over temperature/ short circuit protection
Smart charging system optimizes battery performance
Cold start function
Product Parameter:
Model Name | PS-3K-110V | |
Input Voltage Waveform | Sinusoidal(utility or generator) | |
Rated Power | 3000VA/2400W | |
Input | ||
Voltage | 110VAC | |
Frequency Range | 50HZ/60HZ(Auto Sensing) | |
Output | ||
AC Voltage Regulation | 110VAC | |
Surge Power | 6000VA | |
Wareform | Pure Sine Wave | |
Battery & AC Charger | ||
Battery Voltage | 24VDC | |
Float Voltage | 27VDC | |
Overcharge Protection | 30VDC | |
AC Charging Current | 20A/30A | |
Solar Controller | ||
Charging Current(PWM) | 50A | |
Max PV Array Open Circuit Voltage | 80V | |
Max PV Power Input | 1200W | |
Standby Power Consumption | 2W | |
Battery Connection | |||||||
Model | Typical Amperage | Battery Capacity | Wire Size | Ring Terminal | Torque value | ||
Cable mm2 | Dimensions | ||||||
D(mm) | L(mm) | ||||||
3KVA | 100A | 100AH | 1*4AWG | 22 | 6.4 | 33.2 | |
