Solar Panel 300w 200w 100w 400w PET Flexible Panneau Solaire Kit PV Monocrystalline Cell 12V 24V 1000w Battery Charger System
Shipping Information
For Europe Client: Ship from Spain orFrance Warehouse, Including VAT TAX, 3-10 days arrival via DHL or Post, DPD.
For USA Client: Ship from USA Warehouse, Including VAT TAX, 3-10 days arrival via Post, UPS.
For Russia: Ship from Moscow Warehouse, Including VAT TAX, Fast arrival via Russia Post.
More Oversea Warehouse will open later.
For Spain Island and France Island, there may be extra remote freight cost, so if there were remote cost, then we will contact with buyer.
For USA Client: there are remote area as well, so if your area belongs to remote area, we will contact with you as well.
However, the zip code in Spain that starts with 35, 38, 51, 52 need Shipping from China (Customs clearance fees may apply)
100W Solar kit (1pcs 100w solar panel kits)
Packing listing:
1. 1 pcs 100w solar panel
2. 10A 12v/24v charge controller
3. 1 set Extension cable with PV connector
4. 1 set cable with alligator clip (connect to battery)
200W Solar kit
Packing listing:
1. 2pcs 100w solar panel
2. 20A 12v/24v charge controller
3. 1 set Extension cable with PV connector
4. 1 set cable with alligator clip (connect to battery)
5. 1 set 2 in 1 PV connector (in parallel solar panel
300W Solar kit (3pcs 100w solar panel kits)
Packing listing:
1. 3pcs 100w solar panel
2. 30A 12v/24v charge controller
3. 1 set Extension cable with PV connector
4. 1 set cable with alligator clip (connect to battery)
5. 1 set 3 in 1 PV connector (in parallel solar panel
400W Solar kit (4pcs 100w solar panel kits)
Packing listing:
1. 4pcs 100w solar panel
2. 40A 12v/24v charge controller
3. 1 set Extension cable with PV connector
4. 1 set cable with alligator clip (connect to battery)
5. 1 set 4 in 1 PV connector (in parallel solar panel
100W Solar PanelPacking listing:
1. 1pcs 18V 100w solar panel
2pcs 100W Solar PanelPacking listing:
1. 2pcs 18V 100w solar panel
3pcs 100W Solar PanelPacking listing:
1. 3pcs 18V 100w solar panel
4pcs 100W Solar PanelPacking listing:
1. 4pcs 18V 100w solar panel
Features:
a. Select high-efficiency 158*158mm lines monocrystalline silicon solar cells, the power generation efficiency is about 1.3 times that of conventional polysilicon, and the overall area is smaller at the same power.
b. Semi flexible design,Graceful appearance, delicate and cabinet;
c. The surface is made of PET and treated with a special process, which is more wear-resistant and improves the absorption efficiency of sunlight.
d. Convenience to take , fashionable elegance. PV connector can be suitable to connect controller.
Especially suitable for anywhere can obtain sunshine, realize high-efficient charging, use convenient and safe, environmental protection, energy saving.It is good for promotion, sales, gifts etc.
e. The junction box adopts IP67 waterproof design, contains bypass diode, and the circuit adopts overcharge and reverse current protection design.
f. Use photovoltaic special cable and PV connector, outdoor use is safe, waterproof, high temperature resistance and weather resistance. PV connector is easy to use, plug and play.
g. This product is a solar module. It is recommended to be used with controllers and batteries. It can be used in various scenarios such as households, camping, RVs, yachts, street lights and solar power stations.
Solar panel Technician Specification
Maximum power(Pmax) 100W
Output tolerance + 3%
Maximum system voltage 700V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc) 6A
Maximum power voltage(Vmp) 18V
Maximum power current(Imp) 5A
Cell efficiency 23%
Operating temperature(NOCT) 45±2℃
Temperature range -20℃～+80℃
Number of cells 36pcs
Weight 1650G
Size 1000*500*2.5 mm
Standard Test Conditions : lrradiance 1000w/m2, Temperature 25℃,AM=1.5
Solar panel Electrical Specification
Performance Under Standard Test Conditions(STC*)
Controller connection instructions
a Before connecting the solar panel, please connect the controller to the battery first. Connecting the solar panel without connecting the battery may cause the controller to burn out and fail to display.
b After the controller is connected to the storage battery, connect the above-mentioned series or parallel solar panels to the controller through the transfer cable.
c Finally, connect the required DC load to the load end of the controller. If the load does not work, press the third button of the controller.
d According to the controller manual, adjust the parameters you need.
1set 3M Extension cable
1set 3M cable with alligator clip(Connect the battery)
Notes for use:
a. This product must not come into contact with highly corrosive substances.
b. It is strictly forbidden to modify, disassemble, drop, and hit the junction box and products by yourself, avoid stepping on the surface and scratching the surface with hard objects during use.
c. A large number of scratches or dirt on the surface of the solar panel may cause the solar cell module to be inefficient, and in severe cases may cause burnout.
d. The suitable ambient temperature range of this product: -20 ° C-80 ° C, please do not exceed this range.
e. The solar panel must be installed in an area with good sunlight and no shadow. The long-term work of the solar cell module in the sun with shadow may have the risk of burning.
f. It is forbidden to connect the positive and negative poles of the product together, and it is forbidden to put the product into water or fire, otherwise it will damage the product.
g. The overall power of the photovoltaic module must be less than the rated power of the controller (rated voltage × rated current). It is strictly prohibited to overload the controller.
h. The total voltage of the photovoltaic module connected to the controller must be within the photovoltaic input voltage range of the controller.
i. The inverter can only be connected to the battery, not directly to the controller.
200W kit Black (2pcs 100w black solar panel kits)
