XINPUGUANG 10W 20W 50W Mono Solar Panel 18V High-Efficiency Monocrystalline PV Module Power Charger for RV Marine Rooftop Farm
XINPUGUANG 10W 20W 50W Mono Solar Panel 18V High-Efficiency Monocrystalline PV Module Power Panel Kit Charger for RV Marine Rooftop Farm Boat 12V Battery and Other Off-Grid Applications
50W A1 specifications
Output tolerance ± 3%
Maximum system voltage 700V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc) 3.3A
Maximum power voltage(Vmp) 18V
Maximum power current(Imp) 2.77A
Cell efficiency 21%
Operating temperature（NOCT） 45±2℃
Temperature range -40℃～+80℃
Number of cells 36pcs
Size 680*510*25MM
Product Category Glass panel
Solar cell Mono
Surface material Toughened glass
Back film Color White
Output port 0.5 m long MC 4 connector wire
Standard Test Conditions ： lrradiance 1000w/m^2，Temperature 25℃, AM=1.5
50W A2 specifications
Maximum power(Pmax) 50W
Output tolerance ± 3%
Maximum system voltage 1000V DC
Open circuit voltage(Voc) 23.76V
Short circuit current(Isc) 2.77A
Maximum power voltage(Vmp) 19.8V
Maximum power current(Imp) 2.52A
Cell efficiency 24%
Operating temperature（NOCT） 45±2℃
Temperature range -40℃～+80℃
Cell Monocrystalline silicon
Number of cells 36pcs
Weight 3500g
Size 810*360*25mm
Surface material Toughened glass
Back film Color White
Output port 0.5 m long MC 4 connector wire
Standard Test Conditions ： lrradiance 1000w/m^2，Temperature 25℃, AM=1.5
10W Glass Solar panel Specification:
Output tolerance ± 3%
Maximum system voltage 1000V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc) 0.61A
Maximum power voltage(Vmp) 18V
Maximum power current(Imp) 0.55A
Cell efficiency 21%
Operating temperature（NOCT） 45±2℃
Temperature range -40℃～+80℃
Cell Monocrystalline silicon
Number of cells 36pcs
Weight 1100g
Size 290*275*17mm
Surface material Toughened glass
Back film Color White
Output port 2 m long pv connector wire
Waterproof Yes
Standard Test Conditions ： lrradiance 1000w/m^2，Temperature 25℃, AM=1.5
Maximum power(Pmax) 20W
Output tolerance ± 3%
Maximum system voltage 600V DC
Open circuit voltage(Voc) 21.6V
Short circuit current(Isc) 1.33 A
Maximum power voltage(Vmp) 18V
Maximum power current(Imp) 1.11A
Cell efficiency 23%
Operating temperature（NOCT） 45±2℃
Temperature range -40℃～+80℃
Number of cells 36pcs
Size 410*320*17 mm
Product Category Glass panel
Solar cell Mono
Standard Test Conditions ： lrradiance 1000w/m2，Temperature 25℃,AM=1.5
50W A1 Package list
1 * 18V 50w Glass solar panel
50W A2 Package list
1 * 19.8V 50w Glass solar panel
10W Package list
1 * 10w Glass solar panel
10W Solar kit Package list
1 * 10w Glass solar panel
1*12v/24v 10A controller
1* 2meters 2.5mm² alligator clips
20W Package list
1 * 20w Glass solar panel
20W Solar kit Package list
1 * 20w Glass solar panel
1*12v/24v 10A controller
1* 2meters 2.5mm² alligator clips
50W A1 kit Package list
1、1pcs 50w solar panel
2、1*10A controller
3、1*Alligator clip cable
50W A2 Package list
1 x 50W glass solar panel (12V 50W Solar Kit )
1 x 10A 12V/24V Controller
1 set 3m cable with PV connector
1 set 3m cable with Alligator clip
Features:
【Reliable】Advanced encapsulation material with multi-layered sheet laminations enhance cell performance and provide a long service life.
【Durable】 positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa).
【Versatile】Use it for your RV when camping, or during beach trips with the family, either way this monocrystalline panel provides you with the most efficiency per space.
【Installation Ready】Pre-drilled holes on the back of the panel allow for fast mounting and securing. Pre-drilled holes included for grounding. Compatible with different Renogy mounting systems such as Z-Brackets, Pole Mounts and Tilt Mounts.
Reliable
Advanced encapsulation material with multi-layered sheet laminations enhance cell performance and provide a long service life
EL tested solar modules; no hot-spot heating guaranteed
Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments
TPT back sheet ensures smooth performance over a long period of time
50W A1
50W A1 kit
50W A2
